M80-5004442

Headers, Male Pins Overview

The Harwin M80-5004442 is a male header connector from the Datamate J-Tek series, designed for vertical through-board mounting. It features a 22+22 position configuration with a 3mm pitch and includes jackscrew locking. The contacts are gold-plated beryllium copper pins housed in black PPS insulation, rated for 125°C operation.

Headers, Male Pins Feature Summary

• Vertical through-board mounting style
• Jackscrew locking mechanism
• Gold-plated beryllium copper contacts

Headers, Male Pins Applications

• Power supply units
• Embedded systems
• Automotive solutions

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm the exact pin count and pitch, as variations exist within the M80 series. Ensure compatibility with mating female sockets and check for required accessories like jackscrews or flanges.

Headers, Male Pins Selection Notes

Select this component for high-reliability applications requiring robust mechanical locking via jackscrews. The 3mm pitch offers higher current capacity compared to standard 2mm options, suitable for power distribution tasks.

Headers, Male Pins Part Context

Part of the Datamate J-Tek family, known for modular design and high reliability. This specific model targets industrial and automotive sectors needing secure, high-density connections with easy assembly and disassembly capabilities.

Headers, Male Pins Replacement Considerations

No direct public substitutes identified. Consider Harwin M80 series variants with similar pitch and locking mechanisms if availability is an issue.
