M80-5010805

Headers, Male Pins Overview

The Harwin M80-5010805 is a vertical board-to-board or cable connector header from the Datamate J-Tek series. It features an 8-position configuration with a 2.00mm pitch and 3.5mm mating height. Designed for surface mount installation, it utilizes gold-plated contacts rated for 120V and 2.2A. The housing is constructed from black PPS material compliant with UL94 V-0 standards, ensuring reliable performance in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Surface mount vertical design for space-constrained PCB layouts
• Datamate J-Tek push-pull locking mechanism for secure connection
• Gold-plated phosphor bronze contacts for low resistance
• High-temperature resistant PPS insulation

Headers, Male Pins Applications

• Compact consumer electronics assemblies
• Industrial control system interconnects
• Medical device internal wiring
• Automotive infotainment modules

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm surface mount compatibility and pin configuration. Ensure the ordering part number matches the required contact count and plating thickness specifications. Cross-reference with the latest datasheet to validate environmental ratings and mating partner requirements before procurement.

Headers, Male Pins Selection Notes

Select this component when a vertical surface mount header is required for high-density connections. The 2.00mm pitch allows for compact circuit board designs. Consider the Datamate J-Tek series for its robust mechanical locking and wide temperature range suitability compared to standard through-hole alternatives.

Headers, Male Pins Part Context

This connector belongs to the Datamate J-Tek family, known for high-reliability interconnect solutions. The M80-5010805 variant specifically addresses the need for vertical surface mounting while maintaining the series' characteristic durability and precise alignment capabilities for critical signal and power transmission.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include M80-5010806 for different pin counts. Verify mating receptacles such as M80-4010805 for compatible pairing. Ensure replacement parts maintain identical pitch, locking style, and termination method.
