M80-5021022

Headers, Male Pins Overview

The M80-5021022 is a Datamate J-Tek series board connector manufactured by Harwin Inc. It features a 10-position female socket configuration arranged in two rows with a 2 mm pitch. Designed for surface mount technology, this component utilizes gold-plated beryllium copper contacts to ensure reliable electrical performance. The connector supports a current rating of 3 A and withstands voltages up to 800 VAC/DC. Operating within a temperature range of -55°C to +125°C, it employs Polyphenylene Sulfide (PPS) insulation. Key specifications include an insulation resistance of 100 MOhms and mating stacking heights of 7.55mm, 7.95mm, 10.1mm, 11.1mm, 13.65mm, and 15.1mm.

Headers, Male Pins Feature Summary

• High-reliability four-finger beryllium copper contacts designed to maintain connection integrity under severe vibration, shock, and acceleration conditions.
• Robust Polyphenylene Sulfide (PPS) housing provides thermal stability and chemical resistance for operation in harsh environments.
• Secure locking mechanism ensures durable mating cycles without performance degradation over the product's operational lifespan.

Headers, Male Pins Applications

• Automotive electronics systems requiring high durability
• Military equipment subject to extreme environmental stress
• Industrial control units operating in high-vibration settings

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required surface mount orientation and contact gender. Confirm that the selected stacking height variant aligns with the mechanical design constraints of the target assembly. Ensure compliance with RoHS and REACH regulations as specified in the official datasheet before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when high-current power delivery is required alongside signal transmission in compact spaces. The 2 mm pitch allows for dense circuit layouts while maintaining adequate spacing for high voltage isolation. Consider the available stacking heights to accommodate different board thicknesses or enclosure requirements without compromising mechanical stability.

Headers, Male Pins Part Context

This connector belongs to the Datamate J-Tek family, which is engineered for demanding applications where standard connectors may fail. The series emphasizes mechanical robustness and electrical reliability, making it suitable for sectors such as automotive and defense. The M80-5021022 specifically addresses needs for vertical surface mount integration with secure locking capabilities.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing should be limited to verifying pinout compatibility and mechanical dimensions if alternative sourcing is necessary.
