M80-5024222P

Headers, Male Pins Overview

The Harwin M80-5024222P is a Datamate J-Tek header connector designed for surface mount installation. It features a 21+21 way configuration, providing a total of 42 positions with a 2 mm (0.079 in) pitch. The component utilizes male pin contacts made from phosphor bronze with gold plating, housed in black polyphenylene sulfide (PPS). Rated for 3 A current and 800 V voltage, it operates within a temperature range of -55°C to +125°C. The connector includes keying slots and mating flanges for secure alignment.

Headers, Male Pins Feature Summary

• Surface mount design with vertical orientation for direct PCB integration
• Gold-plated phosphor bronze male pins ensuring reliable electrical contact
• Integrated keying slots and mating flanges for precise alignment

Headers, Male Pins Applications

• Industrial control systems requiring robust power distribution
• Automotive electronics utilizing high-density interconnects
• Telecommunications equipment needing reliable signal transmission

Headers, Male Pins Procurement Notes

Verify the specific suffix 'P' against official Harwin documentation to confirm exact plating thickness or material specifications, as distributor listings may not detail all manufacturing variations. Ensure compatibility with mating sockets regarding height and keying. Confirm RoHS compliance status directly with the manufacturer if required for specific regulatory standards.

Headers, Male Pins Selection Notes

Select this component when a high-density, vertically oriented surface mount header is required. The 2 mm pitch allows for compact board layouts while maintaining 3 A current capacity. Verify that the target application supports the specified operating temperature range and voltage rating. Ensure mechanical clearance accommodates the vertical profile and mounting requirements.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek series by Harwin, known for modular connectivity solutions. The M80-5024222P represents a specific variant within the Power to the Board category, offering a balance of density and reliability. It is engineered for applications demanding secure connections in space-constrained environments.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
