M80-5090442

Headers, Male Pins Overview

The M80-5090442 is a Datamate J-Tek male pin header manufactured by Harwin Inc. It features a 4-position, single-row configuration with a 2.00mm pitch. Designed for through-hole vertical mounting, it utilizes gold-plated phosphor bronze contacts and PPS insulation rated UL94 V-0. The connector supports a current rating of 3A and operates within a temperature range of -55°C to 125°C. It includes a panel mount design suitable for wire-to-board applications.

Headers, Male Pins Feature Summary

• Panel mount construction for secure external access
• Gold-plated phosphor bronze contacts for reliable conductivity
• High-temperature resistant PPS insulation material

Headers, Male Pins Applications

• Wire-to-board interconnections
• Panel-mounted signal access points
• Industrial control interface connections

Headers, Male Pins Procurement Notes

Verify the specific contact plating thickness and insulation material grade against the official Harwin datasheet before integration. Confirm that the panel mount hole dimensions align with your mechanical design requirements. Ensure compatibility with mating sockets from the same Datamate J-Tek series to guarantee proper engagement and electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a vertically oriented, panel-mountable male header is required for low-current signal transmission. The 2.00mm pitch allows for dense packing while maintaining adequate spacing. Consider the 3A current rating and high-temperature tolerance for environments exceeding standard commercial limits. Verify that the single-row format meets the I/O count needs without requiring additional board space.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek series, known for its robust performance in demanding environments. The M80-5090442 specifically addresses the need for accessible, panel-mounted connections within this lineup. Its design complements other J-Tek components, offering a standardized solution for industrial and automotive applications requiring reliable, high-temperature connectivity.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed for this specific panel-mount variant. Cross-referencing with other Harwin Datamate J-Tek headers may provide functional alternatives, but mechanical fit and panel mounting specifics must be verified individually.
