M80-5091042

Headers, Male Pins Overview

The M80-5091042 is a Datamate J-Tek series connector header manufactured by Harwin Inc. It features 10 positions arranged in two rows with a 2.00mm (0.079") mating pitch. Designed for through-hole termination, this female socket connector utilizes beryllium copper contacts with gold plating on the mating interface and tin plating on the tail. The housing is constructed from black polyphenylene sulfide (PPS) reinforced with glass fiber, rated UL94 V-0 for flammability. It supports a maximum voltage of 120V and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Datamate J-Tek series design ensures high reliability and durability under harsh environmental conditions.
• Four-finger beryllium copper contact system provides secure connection integrity against vibration and shock.
• Gold-plated mating surfaces ensure low contact resistance and corrosion resistance.
• Integrated jackscrew locking mechanism prevents accidental disengagement during operation.

Headers, Male Pins Applications

• Automotive electronic systems
• Military and defense equipment
• General industrial control applications

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required pin count and orientation. Confirm that the jack screw locking style is compatible with the assembly constraints. Ensure the operating environment falls within the specified temperature and voltage ratings. Check for any specific packaging requirements if bulk ordering is intended.

Headers, Male Pins Selection Notes

Select this component when a reliable, locked interconnect solution is required for board-to-board or wire-to-board connections. The Datamate J-Tek series is suitable for applications demanding high cycle life and resistance to mechanical stress. Consider the through-hole mounting profile and PCB space requirements before finalizing the design.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek family, known for robust performance in demanding sectors. The M80-5091042 specifically serves as a vertical through-board connector. It pairs with corresponding male headers and cable assemblies within the same series to form complete interconnect solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes are not explicitly listed in the provided documentation. Compatible alternatives may include other Harwin Datamate J-Tek headers with matching pin counts and locking mechanisms, but electrical and mechanical compatibility must be verified against official datasheets.
