M80-5093442

Headers, Male Pins Overview

The M80-5093442 is a Datamate J-Tek female connector with 34 positions arranged in two rows. It features a 2.00mm pitch and utilizes through-hole straight mounting with jackscrew locking. The contacts are gold-plated phosphor bronze, rated for 2.2A at 120V. Operating temperature ranges from -55°C to 125°C. Insulation is black PPS glass-filled.

Headers, Male Pins Feature Summary

• Jackscrew locking mechanism provides secure mating retention
• Shrouded design ensures correct alignment during insertion
• Gold-plated contacts offer reliable signal transmission

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Test and measurement equipment interfaces
• General purpose board-to-board connections

Headers, Male Pins Procurement Notes

Verify the specific contact plating thickness and insulation material grade against the official Harwin datasheet before integration. Confirm that the jackscrew locking style matches the mechanical constraints of the target enclosure design. Ensure compatibility with the corresponding male header series.

Headers, Male Pins Selection Notes

Select this component when high-density 34-position connectivity is required in a compact footprint. The jackscrew feature is ideal for applications needing vibration resistance without soldering the mating interface. Consider the straight orientation for standard PCB layouts where space allows vertical clearance above the board surface.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek family, known for its small form factor and high reliability. It complements male headers within the same series to create complete interconnect solutions. The design supports both wire-to-board and board-to-board configurations depending on the mating partner selected.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Harwin Datamate J-Tek female connectors with identical pin counts and locking styles. Verify that any alternative maintains the same 2.00mm pitch and jackscrew engagement dimensions to ensure mechanical interchangeability.
