M80-5101005

Headers, Male Pins Overview

The Harwin M80-5101005 is a male header connector from the Datamate J-Tek series, designed for power-to-board applications. It features a 10-position configuration with a dual inline (2x5) arrangement and a 2.00mm pitch. The unit utilizes crimp termination for 24-28 AWG wires and includes jackscrew locking mechanisms for secure attachment. Constructed with PPS insulation and gold-plated contacts, it operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Dual inline male pin configuration for high-density power distribution
• Jackscrew locking system ensures secure mechanical retention
• Gold-plated phosphor bronze contacts for reliable conductivity
• Polyphenylene sulfide insulation provides thermal stability

Headers, Male Pins Applications

• Industrial control systems requiring robust power connections
• Automotive electronics and onboard power distribution units
• Telecommunications infrastructure equipment
• Medical device internal power interconnects

Headers, Male Pins Procurement Notes

Verify that the specific suffix indicates the 4.5mm tail length and jack screw variant. Confirm compatibility with mating sockets from the same Datamate J-Tek family. Ensure crimping tools support the specified 24-28 AWG wire gauge range. Check for RoHS compliance documentation if required by project specifications.

Headers, Male Pins Selection Notes

Select this component when a durable, locked power header is needed for board-to-wire connections. The jackscrew feature distinguishes it from latch-based variants, offering superior vibration resistance. Consider the 4.5mm tail dimension for panel clearance requirements. This model suits environments demanding high reliability and thermal endurance up to 125°C.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek line, known for rugged performance in harsh environments. It complements female receptacles and cable assemblies within the same ecosystem. The design emphasizes secure locking and high current capacity compared to standard signal connectors.

Headers, Male Pins Replacement Considerations

• M80-5101005M3

Headers, Male Pins FAQ

What is the contact material used in this connector?

The contacts are made of phosphor bronze with a gold plating finish.

Does this connector use a latching or screw-lock mechanism?

It utilizes a jackscrew locking mechanism for secure attachment.
