M80-5112622

$9.19

Description：CONN HEADER VERT 26POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:395141733261 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M80-5112622 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER VERT 26POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M80-5112622

Description：CONN HEADER VERT 26POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：26
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：0.173" (4.40mm)
Overall Contact Length：-
Insulation Height：0.220" (5.60mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：Tin-Lead
Contact Material：Phosphor Bronze
Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A
Voltage Rating：800V

Headers, Male Pins datasheet and documents for M80-5112622

M80-5112622

Headers, Male Pins Overview

The M80-5112622 is a Datamate J-Tek series header connector manufactured by Harwin Inc. It features a 2x13 pin configuration (26 positions) with a 2.00mm pitch. Designed for vertical through-hole mounting, this male connector utilizes tin/lead plating on phosphor bronze contacts. The housing is constructed from black polyphenylene sulfide (PPS), rated UL94 V-0, and supports an operating temperature range of -55°C to +125°C. Rated at 3A current and 120V voltage, it includes jackscrews for secure attachment.

Headers, Male Pins Feature Summary

Datamate J-Tek modular system compatibility
Vertical through-hole termination style
Integrated jackscrew locking mechanism
High-temperature PPS insulation material

Headers, Male Pins Applications

Industrial control systems
Automotive electronics
Telecommunications equipment
Test and measurement devices

Headers, Male Pins Procurement Notes

Verify the specific suffix '22' confirms tin/lead contact plating rather than gold variants. Confirm the presence of jackscrews in the package description. Ensure the vertical orientation matches the PCB layout requirements. Check RoHS compliance status if lead-free assembly is mandatory for the target application.

Headers, Male Pins Selection Notes

Select this model when a 26-position vertical header with mechanical screw retention is required. Compare against M80-5112642 for gold-plated alternatives. Consider M80-5112605 if surface mount technology is preferred over through-hole. Verify that the 2.00mm row spacing fits within the available board real estate constraints.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek family, known for high-density interconnects. It pairs with female sockets like the M80-41126 series. The design emphasizes robust mechanical stability through jackscrews, distinguishing it from friction-latch variants in the broader connector portfolio.
