M80-5114422

Headers, Male Pins Overview

The Harwin M80-5114422 is a Datamate J-Tek series male header connector designed for through-hole mounting. It features a 2-row configuration with 14 positions and a 2.00mm (0.079 inch) mating pitch. The contacts are constructed from phosphor bronze with gold plating, while the housing is made of black polyphenylene sulfide (PPS) reinforced with glass fiber, rated UL94 V-0. This component supports a maximum current rating of 2.2A and a voltage rating of 800V. It utilizes jackscrew locking mechanisms for secure attachment and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• High-reliability four-finger beryllium copper contact technology ensures connection integrity without signal loss.
• Stainless-steel jackscrew hardware options provide increased security and strain relief.
• Field-proven design offers robust performance in demanding environments.

Headers, Male Pins Applications

• Automotive electronics
• General industrial equipment
• Military applications

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm exact pin count, row configuration, and locking mechanism type. Ensure compatibility with mating receptacles regarding stacking height and keying options. Confirm that the selected variant meets the required environmental ratings for the intended application environment.

Headers, Male Pins Selection Notes

Select this connector when high reliability and secure mechanical locking are required for board-to-board or cable connections. Consider the 800V rating and 2.2A current capacity for power or signal distribution. Evaluate the available stainless-steel jackscrew options for enhanced strain relief needs compared to standard plastic locking methods.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek family, known for its compact size and high-density interconnect capabilities. The M80-5 series specifically denotes male headers with various locking and packaging options. It is part of Harwin's broader portfolio of high-performance connectors used in critical systems requiring long-term stability.

Headers, Male Pins Replacement Considerations

Compatible mating receptacles include models such as M80-4C10605FC and M80-4D10605FC for 6-position configurations, though pin counts must match exactly for direct replacement. Verify stacking height requirements when substituting with other Datamate variants.
