M80-5122642P

$8.93

Description：DATAMATE J-TEK DIL MALE VERTICAL
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:72a731697507 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M80-5122642P is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is DATAMATE J-TEK DIL MALE VERTICAL. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M80-5122642P

Description：DATAMATE J-TEK DIL MALE VERTICAL
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：26
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.234" (5.95mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A
Voltage Rating：800VAC/DC

Headers, Male Pins datasheet and documents for M80-5122642P

M80-5122642P

Headers, Male Pins Overview

The M80-5122642P is a Datamate J-Tek series connector header designed for surface mount applications. It features a dual-row configuration with 26 positions and a 2.00mm mating pitch. The contacts are female sockets made of beryllium copper, finished with gold plating on the mating interface and tin on the termination side. Constructed from black polyphenylene sulfide (PPS) reinforced with glass fiber, it meets UL94 V-0 flammability standards. The component supports a top screw locking mechanism and includes polarizing keys for secure alignment.

Headers, Male Pins Feature Summary

Surface mount vertical design for automated assembly processes
Top screw locking system ensures robust mechanical retention
Gold-plated beryllium copper contacts provide reliable conductivity
Glass-filled PPS insulation offers high thermal stability

Headers, Male Pins Applications

Automotive electronic control units
General industrial equipment interconnects
Military grade circuit board assemblies

Headers, Male Pins Procurement Notes

Verify part status as this specific suffix variant is listed as obsolete. Confirm availability of direct replacements such as M80-4022642. Ensure procurement channels source genuine Harwin components to guarantee compliance with RoHS3 specifications and material integrity.

Headers, Male Pins Selection Notes

Select this component when surface mount technology is required for high-reliability connections. The 26-position count suits complex signal routing. Verify that the PCB layout accommodates the specified stacking heights and that the top screw locking feature aligns with the enclosure design constraints.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek family, characterized by 2mm pitch connectors engineered for harsh environments. The series withstands vibration, shock, and extreme temperatures. The M80-5122642P represents a specialized surface mount variant within this high-performance ecosystem.
