M80-5221442

Headers, Male Pins Overview

The M80-5221442 is a Datamate J-Tek series header connector manufactured by Harwin Inc. It features a vertical through-hole mounting style with a 2mm (0.079 inch) mating pitch and a 2mm row spacing. The component provides 21+21 positions, totaling 42 contacts, arranged in two rows. It utilizes male pin contacts made from phosphor bronze with gold plating. The housing is constructed from black polyphenylene sulfide (PPS) reinforced with glass fiber, rated UL94 V-0 for flammability. The connector supports a maximum operating temperature range of -55°C to +125°C and carries a current rating of 3A.

Headers, Male Pins Feature Summary

• High-reliability four-finger beryllium copper contact technology ensures connection integrity without loss.
• Datamate J-Tek system offers push-pull locking mechanism for secure board-to-board or cable connections.
• Shrouded design with keying options prevents misalignment during mating.
• Gold-plated contacts provide corrosion resistance and low contact impedance.

Headers, Male Pins Applications

• Automotive electronics systems
• Industrial control equipment
• Military and defense applications

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against the official Harwin datasheet to confirm exact pin count, plating thickness, and keying configuration. Ensure compatibility with mating receptacles within the same Datamate J-Tek family. Check for RoHS compliance status if required by project specifications. Confirm lead times as they may vary based on manufacturing schedules.

Headers, Male Pins Selection Notes

Select this part for high-density interconnect needs requiring robust mechanical retention. The 2mm pitch allows for compact PCB layouts while maintaining reliable signal transmission. Consider the shrouded design for protection against accidental short circuits. Verify that the mating connector matches the male pin configuration and locking style.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek family, known for its high reliability in harsh environments. It complements other Harwin connectors like the M80-4 series receptacles. The design emphasizes durability and consistent performance across automotive and industrial sectors.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin Datamate J-Tek headers with matching 2mm pitch and 42-position configurations. Ensure equivalent locking mechanisms and contact materials are maintained for interchangeability.
