M80-5322042

Headers, Male Pins Overview

The M80-5322042 is a Datamate J-Tek male pin header connector manufactured by Harwin Inc. It features a 2mm pitch and a 20-position configuration arranged in two rows. Designed for surface mount installation, this component utilizes right-angle termination to facilitate board-to-board or cable connections. The contacts are constructed from phosphor bronze with gold plating on the mating interface and tin plating on the tail, ensuring reliable conductivity. The housing is made of black polyphenylene sulfide (PPS) reinforced with glass fiber, providing structural integrity and UL94 V-0 flammability rating. Rated for 2.2A current and 120V voltage, it operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• High-reliability Datamate J-Tek series construction
• Gold-plated contacts for enhanced corrosion resistance
• Shrouded four-wall housing for secure mating alignment

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Automotive electronics applications
• Telecommunications equipment
• Medical device circuitry

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as datasheets may indicate varying environmental declarations depending on production batch. Confirm that the specific suffix matches the required right-angle orientation and surface mount termination type. Ensure compatibility with mating sockets from the same Datamate J-Tek family. Check for any recent product change notices regarding material substitutions or manufacturing location changes before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this part when a right-angle surface mount header is required for high-density layouts. The 2mm pitch allows for significant I/O density compared to larger pitches. Consider the 2.2A current rating against total system load requirements. The PPS material offers superior thermal stability compared to standard nylons. Verify that the PCB footprint accommodates the right-angle tail dimensions and solder mask clearance requirements for automated assembly processes.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek series, known for high reliability in demanding environments. It is distinct from the L-Tek series which typically uses different contact geometries and materials. The M80-5322042 specifically denotes a 20-position, two-row, surface mount, right-angle variant. It pairs with corresponding female sockets such as those in the M80-4xxxxxx series to complete the connection system.

Headers, Male Pins Replacement Considerations

M80-5322022 is listed as an equivalent or substitute part number. Verify if the suffix difference indicates a variation in packaging, plating thickness, or specific mechanical tolerances before substitution. No other direct cross-model substitutes are publicly confirmed for this exact specification.

Headers, Male Pins FAQ

What is the contact material used in the M80-5322042?

The contacts are made from phosphor bronze to ensure good spring properties and conductivity.

Is the connector shrouded?

Yes, the M80-5322042 features a shrouded four-wall housing design to guide mating and prevent misalignment.

What is the maximum operating temperature?

The rated operating temperature range extends up to +125°C.
