M80-5401042

$19.18

Description：CONN HEADER R/A 10POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:66cb2d9f85c2 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M80-5401042 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER R/A 10POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M80-5401042

Description：CONN HEADER R/A 10POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：10
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：-
Insulation Height：0.218" (5.55mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A
Voltage Rating：800V

Headers, Male Pins datasheet and documents for M80-5401042

M80-5401042

Headers, Male Pins Overview

The Harwin M80-5401042 is a 10-position, 2-row male pin header from the Datamate J-Tek series. It features a 2mm pitch and right-angle through-hole mounting with a 3mm tail length. Rated for 3A current and 120V voltage, it operates between -55°C and 125°C. The housing is black PPS (UL94 V-0), and contacts are phosphor bronze with gold plating on the mating interface and tin on the posts.

Headers, Male Pins Feature Summary

Datamate J-Tek system provides high reliability with polarizing keys and jackscrew locking options.
Gold-plated signal contacts ensure stable electrical performance in demanding environments.
Right-angle design facilitates compact board-to-board or wire-to-board interconnections.

Headers, Male Pins Applications

Automotive electronics
Military systems
General industrial equipment

Headers, Male Pins Procurement Notes

Verify the specific suffix against the official datasheet to confirm contact finish and mechanical variations. Ensure compatibility with mating sockets and jackscrews. Confirm RoHS compliance status for the specific production batch. Check lead times as they may vary by region.

Headers, Male Pins Selection Notes

Select this component for applications requiring robust signal transmission with secure locking mechanisms. The right-angle form factor aids in space-constrained layouts. Verify that the 3A rating meets circuit requirements. Consider the operating temperature range for environmental suitability.

Headers, Male Pins Part Context

Part of the Datamate J-Tek family, designed for high-reliability power and signal connections. The series supports various configurations including board-to-board and wire-to-board interfaces. Known for durability in harsh conditions.

Headers, Male Pins Replacement Considerations

M80-5401042 is a specific variant within the M80-540 base series. Cross-reference with other M80-540xx42 models for different tail lengths or contact finishes. Ensure mechanical dimensions match the PCB layout.
