M80-5401422

Headers, Male Pins Overview

The Harwin M80-5401422 is a Datamate J-Tek series power-to-board connector designed for vertical throughboard mounting. It features a female socket configuration with four positions arranged in a dual in-line layout. The component utilizes a 2 mm pitch and supports a current rating of 3 A with a voltage rating of 800 VAC/DC. Constructed with beryllium copper contacts gold-plated for conductivity, the housing is made of black polyphenylene sulfide (PPS). It operates within a temperature range of -55 C to +125 C and offers an insulation resistance of 100 MOhms.

Headers, Male Pins Feature Summary

• Secure and robust connection design suitable for demanding applications
• Gold-plated beryllium copper contacts ensure reliable signal integrity
• Polyphenylene sulfide housing provides high thermal stability

Headers, Male Pins Applications

• Power distribution on printed circuit boards
• Industrial control systems requiring secure connections
• High reliability electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific pin count and contact type against project requirements before ordering. Confirm that the vertical throughboard mounting style aligns with the PCB layout constraints. Ensure the operating environment falls within the specified temperature range. Check for RoHS compliance status if required by regional regulations. Validate the supplier's authenticity to prevent counterfeit components.

Headers, Male Pins Selection Notes

Select this part when a compact, secure female connector is needed for vertical board mounting. Consider the 2 mm pitch for spacing requirements and the 3 A current rating for load capacity. Evaluate the need for reverse fix capabilities if vibration resistance is critical. Compare against other Datamate variants for different orientation or contact configurations.

Headers, Male Pins Part Context

This component belongs to the Harwin Datamate J-Tek family, known for high-reliability interconnect solutions. The series offers various configurations including male and female options with different mounting styles. It is widely used in industries requiring robust performance under harsh conditions.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official Harwin resources for compatible alternatives.
