M80-5414005

Headers, Male Pins Overview

The M80-5414005 is a 14-position male header connector from the Harwin Datamate J-Tek series. It features a 2-row configuration with a 2.00mm (0.079 inch) pitch and is designed for surface-mount installation. The connector utilizes gold-plated contacts suitable for signal applications, housed in a black polyphenylene sulfide (PPS) insulator reinforced with glass fiber. Rated for operation between -55°C and +125°C, it employs jackscrew locking mechanisms to ensure secure mating. This component supports mixed-signal environments within compact board-to-board or cable assemblies.

Headers, Male Pins Feature Summary

• Surface-mount termination method for automated PCB assembly
• Jackscrew locking system provides positive mechanical retention
• Gold-plated contacts ensure reliable signal transmission
• High-temperature resistant PPS insulation material

Headers, Male Pins Applications

• Compact electronic device interconnects
• Industrial control module connections
• Automotive electronics subsystems
• Telecommunications equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against the official Harwin datasheet to confirm exact pinout, plating thickness, and mounting orientation. Ensure compatibility with mating receptacles from the same Datamate J-Tek family. Confirm that the surface-mount footprint matches the target PCB design requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this model when surface-mount technology is required for high-density interconnects. The 2.00mm pitch allows for compact layouts while maintaining robust mechanical stability through jackscrew fastening. Consider the operating temperature range and contact plating specifications to ensure suitability for the intended environmental conditions and signal integrity requirements.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek product line, known for high-reliability rectangular connectors. The M80-5414005 specifically addresses needs for rigid surface-mount headers in space-constrained applications. It complements the broader M80 ecosystem by providing standardized interface solutions for various industrial and commercial sectors requiring durable electrical connections.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 14-pin count, 2.00mm pitch, and surface-mount configuration. Verify that alternative components support identical jackscrew locking mechanisms and compatible mating geometries. Cross-reference with Harwin's official replacement guides to ensure functional equivalence without redesigning the host PCB layout.
