M80-5421022

Headers, Male Pins Overview

The M80-5421022 is a Datamate J-Tek power-to-board header manufactured by Harwin Inc. It features a dual-row configuration with 10 positions (5+5) and a 2 mm pitch. The connector utilizes male pin contacts made of brass with gold plating, housed in black polyphenylene sulfide (PPS). Designed for surface mount technology (SMT), it offers a straight mounting style with solder termination. The component supports a current rating of 3 A and operates within a temperature range of -55°C to +125°C. Insulation resistance is specified at 100 MOhms.

Headers, Male Pins Feature Summary

• Datamate J-Tek series interconnect system designed for high-density power applications
• Surface mount horizontal orientation with jack screw locking mechanism for secure mating
• Gold-plated brass contacts ensuring reliable electrical conductivity and corrosion resistance
• Polyphenylene sulfide housing providing thermal stability and mechanical strength

Headers, Male Pins Applications

• Power distribution on printed circuit boards
• Industrial control systems requiring robust board-to-board connections
• Automotive electronics modules
• General purpose electronic equipment

Headers, Male Pins Procurement Notes

Verify the RoHS compliance status carefully as documentation indicates non-compliance. Confirm the specific manufacturing date code and lot traceability requirements for your production line. Ensure that the jack screw accessory is included or ordered separately if required for your assembly process. Cross-reference the official datasheet for any recent design changes or obsolescence notices before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a horizontal SMT header with jack screw locking is required for power delivery. The 2 mm pitch allows for moderate density while maintaining 3 A current capacity per contact. Consider the 125°C maximum operating temperature for high-heat environments. Verify that the PCB footprint matches the specific SMT pad layout for this part number to ensure proper reflow soldering results.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate J-Tek family, known for its modular design and push-pull or jack screw locking options. The M80-5421022 specifically addresses the need for horizontal surface mount headers in power-to-board scenarios. It complements female sockets and cable assemblies within the same ecosystem, allowing for flexible system integration across various industrial and commercial sectors.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available.
