M80-5434242

Headers, Male Pins Overview

The M80-5434242 is a surface-mount header from the Harwin Datamate J-Tek series, featuring a 2mm pitch and 42 positions in a dual-row configuration. It utilizes right-angle termination for board-to-board or cable applications. The connector is rated for 120V AC/DC with a 3A current capacity. Contacts are made of phosphor bronze with gold plating, housed in black PPS insulation. It supports solder termination and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Datamate J-Tek series interconnect system
• Right-angle surface mount termination
• Shrouded four-wall housing design
• Gold-plated phosphor bronze contacts

Headers, Male Pins Applications

• Board-to-board connections
• Cable-to-board assemblies
• Industrial control systems
• Automotive electronics

Headers, Male Pins Procurement Notes

Verify the specific suffix '42' confirms the 42-position count and '42' indicates the contact arrangement. Confirm the 'SMD R/A' designation matches the required right-angle orientation for the PCB layout. Ensure compatibility with the mating socket series. Check RoHS compliance status if required by project specifications.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle surface-mount header is required. The 2mm pitch allows for compact designs. The shrouded design provides alignment and protection. Consider the 3A rating for power distribution needs. Verify the operating temperature range meets environmental requirements.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek family, known for push-pull locking mechanisms. It is designed for reliable signal and power transmission in space-constrained environments. The series offers various pin counts and termination styles to suit different assembly needs.

Headers, Male Pins Replacement Considerations

M80-5434242-ND is the DigiKey equivalent identifier. Cross-reference with other Harwin M80-54 series variants for similar form factors. Ensure mating connectors share the same pitch and locking mechanism.
