M80-5435005

Headers, Male Pins Overview

The Harwin M80-5435005 is a Datamate J-Tek power connector designed for horizontal surface mount technology (SMT) board mounting. It features a 2 mm pitch and a dual-row configuration with 8 positions. The component utilizes crimp termination for wire connections and operates within a temperature range of -55°C to +125°C. Constructed with Polyphenylene Sulfide (PPS) housing and gold-plated contacts, it supports a current rating of 3 A per contact.

Headers, Male Pins Feature Summary

• Horizontal surface mount design for compact PCB integration
• Crimp termination ensures reliable wire-to-board connections
• High-temperature PPS housing provides thermal stability

Headers, Male Pins Applications

• Power distribution in industrial control systems
• Board-to-board power interfaces in telecommunications equipment
• Embedded power supply modules in automotive electronics

Headers, Male Pins Procurement Notes

Verify the specific datasheet version and RoHS compliance status prior to procurement, as regulatory documentation may vary by production batch. Confirm that the horizontal SMT footprint matches the target PCB layout dimensions exactly. Ensure compatibility with standard reflow soldering profiles for the specified Polyphenylene Sulfide material to maintain structural integrity during assembly.

Headers, Male Pins Selection Notes

Select this component when a low-profile horizontal connection is required for power delivery in space-constrained designs. The 2 mm pitch allows for moderate density without excessive board area usage. Verify that the 3 A current rating aligns with the circuit load requirements. Consider the crimp termination method if pre-assembled wires are preferred over through-hole soldering for the input side.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate J-Tek family, which specializes in high-reliability interconnect solutions. The series is engineered for demanding environments, offering robust mechanical locking and consistent electrical performance. The M80 series specifically focuses on power applications, providing durable connections for critical infrastructure and electronic systems requiring long-term stability.

Headers, Male Pins Replacement Considerations

No officially confirmed substitute part numbers are available in public documentation. Due to the specific horizontal SMT footprint and crimp termination style, direct replacements must match these physical and electrical characteristics precisely. Consult Harwin technical support for potential obsolescence management or alternative series recommendations.
