M80-5520605

Headers, Male Pins Overview

The M80-5520605 is a male header connector from the Harwin Datamate J-Tek series, designed for power-to-board applications. It features 6 positions with a 2mm pitch and utilizes a surface mount installation style. The connector supports a current rating of 3A and employs gold-plated brass contacts housed in a Polyphenylene Sulfide (PPS) shell. It is characterized by a right-angle configuration suitable for compact board layouts.

Headers, Male Pins Feature Summary

• Right-angle surface mount design for space-efficient PCB integration
• Gold-plated brass contacts ensure reliable conductivity
• Polyphenylene Sulfide housing provides structural stability

Headers, Male Pins Applications

• Power distribution on printed circuit boards
• Compact electronic device interconnects
• High-density board-to-board connections

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm exact mechanical dimensions and soldering profile requirements. Ensure compatibility with mating female connectors within the same Datamate J-Tek family. Check for any recent discontinuation notices or lifecycle status updates before finalizing component selection for long-term production.

Headers, Male Pins Selection Notes

Select this part when a right-angle, surface-mount male header is required for power applications. The 6-position count and 2mm pitch define the interface density. Consider the 3A current rating against system load requirements. Verify that the surface mount footprint matches the target PCB design constraints.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek series, known for high-reliability interconnect solutions. The M80-5520605 specifically addresses needs for robust power delivery in constrained spaces. Its classification as a power-to-board connector distinguishes it from standard signal headers in the same product line.

Headers, Male Pins Replacement Considerations

M80-5520642
