M80-5C10605M5

$9.62

Description：CONN HEADER SMD R/A 6POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:04c6ab045b8f Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M80-5C10605M5 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER SMD R/A 6POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M80-5C10605M5

Description：CONN HEADER SMD R/A 6POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：6
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.219" (5.56mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：-
Contact Material：Brass
Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A per Contact
Voltage Rating：800V

Headers, Male Pins datasheet and documents for M80-5C10605M5

M80-5C10605M5

Headers, Male Pins Overview

The M80-5C10605M5 is a male header connector from the Harwin Datamate J-Tek series. It features a 2-row, 6-position configuration with a 2.00mm pitch. Designed for panel mount installation at a right angle, it utilizes crimp termination for discrete cables rated between 24 and 28 AWG. The contacts are gold-plated to ensure reliable signal transmission. This component employs jackscrew locking mechanisms for secure mating and includes shielding capabilities.

Headers, Male Pins Feature Summary

Panel-mounted right-angle design for space-constrained applications
Gold-plated contacts for corrosion resistance and conductivity
Jackscrew locking system for secure connection retention
Shielded construction for electromagnetic interference protection

Headers, Male Pins Applications

Industrial control systems requiring robust interconnects
Telecommunications equipment housing
Medical device internal wiring
Automotive electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm cable gauge compatibility and termination style. Ensure that the selected variant matches the required shielding and locking mechanism specifications for the target application environment. Cross-reference the manufacturer's latest documentation to confirm current production status and availability before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this connector when a shielded, panel-mount solution with high vibration resistance is required. The Datamate J-Tek series offers a compact footprint suitable for dense layouts. Consider the crimping tool requirements for the specified wire gauge range during the assembly process planning phase.

Headers, Male Pins Part Context

This component belongs to the Datamate J-Tek family, known for high-reliability interconnects in harsh environments. The series provides various configurations including board-to-board and cable-to-board options. The M80-5C10605M5 specifically addresses needs for shielded, angled panel mounting with screw-locking security.
