M80-5L10205M5-04-333-00-000

Headers, Male Pins Overview

The M80-5L10205M5-04-333-00-000 is a Datamate Mix-Tek board connector featuring 7+7 positions in a dual-in-line configuration. It utilizes male contacts designed for 22 AWG cables, supporting power-to-board applications. The component employs a panel mount installation method with a crimp termination style. Constructed with gold-plated terminals and black insulators, it ensures reliable electrical connectivity within mixed-signal environments.

Headers, Male Pins Feature Summary

• Supports mixed signal applications through combined power and signal contact arrangements
• Features male contacts optimized for direct cable connection via crimp termination
• Designed for secure panel mounting to facilitate robust power delivery systems

Headers, Male Pins Applications

• Power-to-board interconnects requiring mixed signal transmission
• Panel-mounted equipment needing reliable cable connections
• Industrial control systems utilizing Datamate Mix-Tek series components

Headers, Male Pins Procurement Notes

Verify the specific pin configuration and contact gender against project requirements before procurement. Confirm that the 22 AWG cable gauge compatibility matches existing harness specifications. Ensure panel mounting dimensions align with the enclosure design constraints. Cross-reference the official Harwin datasheet for precise mechanical tolerances and material certifications to guarantee compliance with system standards.

Headers, Male Pins Selection Notes

Select this component when a mixed-signal solution combining power and data transmission is required in a single connector interface. The male contact type necessitates mating with female counterparts or cable assemblies. Consider the panel mount orientation and 22 AWG wire gauge limitations during mechanical integration planning to ensure proper fit and electrical performance within the target application environment.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate Mix-Tek family, which integrates power and signal contacts within a single housing. The series supports various configurations for diverse electronic interconnect needs. As a specialized board connector, it facilitates compact designs where space efficiency and mixed-signal capability are critical for system architecture and operational reliability.

Headers, Male Pins Replacement Considerations

Consult official Harwin documentation for verified substitute part numbers. Ensure any replacement maintains identical contact count, gender, and termination style. Verify mechanical compatibility including panel mount dimensions and cable gauge support before implementation.
