M80-5L10422M5-02-333-00-000

Headers, Male Pins Overview

The Harwin M80-5L10422M5-02-333-00-000 is a Datamate J-Tek male header connector designed for power-to-board applications. It features a 6-position configuration with a 2mm pitch and dual-row arrangement. The component utilizes brass contacts with gold plating and a Polyphenylene Sulfide (PPS) housing. Rated for 3A current, it supports through-hole mounting with solder pin termination. Operating temperatures range from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Datamate J-Tek series construction with high-reliability locking mechanisms
• Gold-plated brass contacts ensuring stable electrical performance
• Polyphenylene Sulfide (PPS) housing material for thermal stability

Headers, Male Pins Applications

• Power distribution in industrial control systems
• Embedded electronics interconnects
• Telecommunications equipment power interfaces

Headers, Male Pins Procurement Notes

Verify the specific ordering suffixes against official Harwin documentation to ensure correct contact type and mounting style. Confirm RoHS compliance status directly with the manufacturer or authorized distributors prior to procurement. Cross-reference the full part number to avoid confusion with similar Datamate variants.

Headers, Male Pins Selection Notes

Select this component when a 6-position male header is required for board-to-board or cable connections. Ensure the design accommodates the 2mm pitch and through-hole footprint. Verify that the 3A current rating and temperature range meet the system's operational requirements.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate J-Tek family, known for robust rectangular connectors. It serves as a male header variant within the broader M80 series, providing reliable power and signal transmission solutions for compact electronic assemblies requiring durable interconnects.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Harwin Datamate J-Tek male headers with identical 6-position, 2mm pitch specifications. Verify compatibility of mating sockets and locking mechanisms before substitution.
