M80-5L10805M7-06-333-00-000

Headers, Male Pins Overview

The M80-5L10805M7-06-333-00-000 is a Datamate L-Tek connector header manufactured by Harwin Inc. It features an 8-position configuration with a 2.00mm pitch across two rows. The component utilizes male pin contacts with gold plating and supports 22 AWG wire gauges. Designed for cable mount applications, it employs a crimp termination method. The housing is black, and the unit operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Datamate L-Tek series construction for reliable interconnection
• Gold-plated male pins ensure low contact resistance
• Crimp termination facilitates secure wire attachment
• Dual-row layout accommodates compact circuit designs

Headers, Male Pins Applications

• Industrial control system wiring harnesses
• Consumer electronics internal connections
• Automotive sensor interface modules
• Medical device signal transmission lines

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm mechanical dimensions and mating compatibility. Ensure the selected variant matches the required wire gauge and termination style for your assembly process. Cross-reference the manufacturer part number with authorized distributors to avoid counterfeit components. Confirm RoHS compliance status if environmental regulations apply to your project requirements.

Headers, Male Pins Selection Notes

Select this component when a dual-row, 8-position header is required for cable-to-board connections. Consider the 2.00mm pitch constraint and crimp termination method during PCB or harness design. Evaluate the operating temperature range and current carrying capacity against system demands. Compare against other Datamate series options if different locking mechanisms or housing colors are needed.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate family, known for high-density interconnect solutions. The L-Tek sub-series specifically targets cost-effective applications while maintaining robust performance standards. It complements female socket counterparts to form complete connector pairs. The product line emphasizes versatility in mounting styles and contact configurations for diverse electronic assemblies.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Verify compatibility with mating sockets from the same Datamate L-Tek series before substitution. Generic equivalents may not match the precise pitch or locking mechanism requirements.
