M80-5L10822M5-08-333-02-333

Headers, Male Pins Overview

The M80-5L10822M5-08-333-02-333 is a Datamate Mix-Tek male header connector from Harwin Inc. It features a 2-position configuration with a 2.00mm pitch. Designed for vertical through-hole mounting, it utilizes a single in-line (SIL) arrangement. The component includes integrated shielding and supports board-to-wire applications.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series integration
• Integrated electromagnetic shielding
• Vertical through-hole termination

Headers, Male Pins Applications

• Board-to-wire interconnects
• Shielded signal routing
• Compact electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to ensure correct pin count and termination style. Confirm that the shielding requirements match the application environment. Check for RoHS compliance status in the latest datasheet before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this part for applications requiring mixed-signal connectivity with integrated shielding. Ensure the vertical form factor fits the mechanical constraints. Verify that the 2.00mm pitch aligns with mating connector specifications and PCB layout requirements.

Headers, Male Pins Part Context

This component belongs to the Datamate Mix-Tek family, designed for high-density power and signal transmission. It combines standard signal pins with dedicated power contacts within a compact housing, offering reliable performance in space-constrained industrial and consumer electronics.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available. Cross-reference only with other Harwin Datamate Mix-Tek variants sharing identical pitch, shielding, and mounting characteristics.
