M80-5L10822MC

Headers, Male Pins Overview

The M80-5L10822MC is a male header connector from the Harwin Datamate J-Tek series. It features a 2mm pitch and a 1+1 row configuration with 2 positions. The contacts are gold-plated phosphor bronze pins designed for crimp termination on 24-28 AWG wire. The housing is black polyphenylene sulfide (PPS) rated UL 94 V-0. Electrical ratings include 3A current and 120V voltage, operating within -55°C to +125°C.

Headers, Male Pins Feature Summary

• Datamate J-Tek high-reliability interconnect system
• Crimp termination for discrete wire applications
• Gold-plated contacts for corrosion resistance
• Polyphenylene sulfide housing material

Headers, Male Pins Applications

• Industrial control systems
• Medical device wiring
• Telecommunications equipment
• Automotive electronics

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure correct contact gender and termination style. Confirm that the required cable gauge matches the 24-28 AWG specification. Check for RoHS compliance status if restricted substances are a concern. Ensure mating connectors utilize compatible female sockets from the same Datamate family.

Headers, Male Pins Selection Notes

Select this component when a low-profile, free-hanging male header is required for wire-to-board connections. The 2mm pitch allows for dense packing in limited spaces. Verify that the application environment stays within the specified temperature range. Consider the locking mechanism requirements of the mating socket for secure assembly.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek and J-Tek families, known for their robust mechanical performance. The M80 series is widely used in harsh environments due to its durable PPS housing and reliable crimp contacts. It serves as a standard solution for power and signal distribution in compact electronic assemblies.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Cross-reference with other Harwin Datamate male headers if pin count or pitch differs. Ensure any alternative maintains the same 2mm pitch and crimp termination type for compatibility.
