M80-5L11042M5

Headers, Male Pins Overview

The Harwin M80-5L11042M5 is a Datamate J-Tek series power-to-board connector header. It features 10 positions in a single row with a 2.00mm pitch. The component utilizes male pin contacts made of brass with gold plating, housed in a black polyphenylene sulfide (PPS) insulator. Designed for surface mount technology (SMD/SMT), it employs solder terminals for board attachment. The unit supports a rated current of 3A and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Datamate J-Tek series construction for reliable power delivery
• Surface mount installation for automated assembly processes
• Gold-plated brass contacts ensuring stable conductivity
• High-temperature resistant PPS housing material

Headers, Male Pins Applications

• Industrial control systems requiring robust power connections
• Automotive electronics applications
• General purpose PCB power distribution
• Military equipment interconnects

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Harwin documentation to confirm exact tail length and locking mechanism variations. Ensure compatibility with mating receptacles from the same Datamate J-Tek family. Confirm RoHS compliance status through the manufacturer's latest datasheet before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount power header is required. The 2.00mm pitch allows for dense circuit layouts while maintaining adequate spacing for high-current applications. Consider the straight configuration for standard vertical mounting orientations on the printed circuit board.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek product line by Harwin, specialized for power-to-board interconnections. The series is known for its compact form factor and high reliability in demanding environments. It complements other connectors in the M80 family designed for mixed signal and power applications.

Headers, Male Pins Replacement Considerations

Direct substitutes are limited due to proprietary design specifics. Evaluate other Harwin Datamate headers with identical 10-position SMT configurations. Verify mechanical dimensions and electrical ratings match before considering alternative manufacturers' equivalents.

Headers, Male Pins FAQ

What is the contact material used in this connector?

The contacts are manufactured from brass and feature a gold plating finish.

Is this connector suitable for high-temperature environments?

Yes, it is rated for operation up to +125°C using PPS insulation material.
