M80-5L11242MC

Headers, Male Pins Overview

The Harwin M80-5L11242MC is a male header connector from the Datamate J-Tek series, designed for power distribution applications. It features a 6+6 position configuration with a 2.00mm pitch and accepts 24-28 AWG wire. The component utilizes a latched housing mechanism for secure cable attachment and employs gold-plated contacts to ensure reliable electrical performance in high-current scenarios.

Headers, Male Pins Feature Summary

• Configured as a male header for robust power transmission
• Features a latched housing design for secure cable retention
• Utilizes gold-plated contacts to maintain signal integrity

Headers, Male Pins Applications

• Power distribution modules
• Industrial control systems
• High-current circuit interconnections

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 6+6 position configuration and latched housing style. Confirm compatibility with the intended wire gauge range of 24-28 AWG. Ensure the mating interface aligns with the corresponding female receptacle specifications to guarantee proper mechanical engagement and electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a dedicated power-to-board solution is required within the Datamate ecosystem. The male header format is suitable for connecting power sources to downstream circuitry. Consider the latching feature if vibration resistance or secure cable retention is critical for the assembly environment.

Headers, Male Pins Part Context

This connector belongs to the Datamate J-Tek family, which specializes in mixed-signal and power interconnect solutions. The series supports various configurations to accommodate different current loads and pin counts, providing a standardized interface for board-to-cable connections in demanding electronic applications.

Headers, Male Pins Replacement Considerations

No direct substitute part numbers are documented in the provided source material.
