M80-5L11442M7

Headers, Male Pins Overview

The Harwin M80-5L11442M7 is a Datamate J-Tek male header connector designed for through-board mounting. It features a 3+3 position configuration with a 2mm pitch and double in-line layout. The unit utilizes jackscrew locking mechanisms for secure attachment. Contacts are gold-plated brass, housed in black polyphenylene sulfide (PPS) insulation. It supports up to 2.2A current at 800VAC/DC, operating within -55°C to +125°C.

Headers, Male Pins Feature Summary

• Jackscrew locking system ensures positive mechanical retention
• Double in-line male pin configuration for compact density
• High voltage rating capability for power applications

Headers, Male Pins Applications

• Industrial control panel interconnections
• Power distribution modules
• Automotive electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix 'M7' against official Harwin documentation to confirm jack screw type and housing variations. Ensure compatibility with mating sockets regarding current derating curves and thermal management requirements. Cross-reference the datasheet for precise dimensional tolerances required by the PCB footprint design.

Headers, Male Pins Selection Notes

Select this component when high-voltage isolation and robust mechanical locking are required in space-constrained environments. The horizontal through-board style suits applications needing direct board-to-board or cable-to-board connections with fixed orientation. Consider the 2mm pitch for signal density needs.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek series, known for high-reliability interconnects. It complements female receptacles and cable assemblies within the same ecosystem. The series supports various termination styles and contact counts, offering modular solutions for diverse electronic packaging challenges.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Verify if generic 2mm pitch headers meet the specific jackscrew locking and voltage rating requirements before considering alternatives.
