M80-5L13422MC

Overview

The M80-5L13422MC is a Datamate J-Tek male header connector manufactured by Harwin Inc. It features a 34-position, dual-row configuration with a 2.00mm pitch and right-angle mounting style. The connector utilizes phosphor bronze contacts with gold plating for the mating interface and tin plating for the tail. It is designed for board-to-board or cable applications, offering a shrouded four-wall shield structure. The unit employs a push-turn locking mechanism and includes keying slots and mating flanges for secure assembly.

Feature Summary

• Right-angle surface mount design for compact PCB integration
• Push-turn locking system ensures secure mechanical retention
• Shrouded four-wall shielding provides environmental protection
• Keyed slot and mating flange facilitate precise alignment

Applications

• Board-to-board interconnections in industrial equipment
• Cable-to-board connections in control systems
• Automotive electronic module interfaces
• High-density signal routing in compact enclosures

Procurement Notes

Verify component authenticity through authorized Harwin distributors. Confirm that the part number matches the specific right-angle, 34-position variant. Check for RoHS compliance documentation if required by project specifications. Ensure storage conditions maintain contact integrity prior to assembly.

Selection Notes

Select this model when right-angle mounting and high pin counts are required. The push-turn lock offers superior vibration resistance compared to standard headers. Verify PCB space constraints accommodate the right-angle profile. Ensure mating connectors match the Datamate J-Tek series specifications.

Part Context

This component belongs to the Datamate J-Tek series, known for high reliability in harsh environments. The M80-5L1 prefix indicates a right-angle male header within the broader connector family. It complements socket counterparts for complete interconnect solutions.

Replacement Considerations

M80-5L13422MC is obsolete. Official substitutes include M80-5L13422MD or M80-5L13422MX. Verify pin count, pitch, and locking mechanism compatibility before substitution.
