M80-5L13442MC

Headers, Male Pins Overview

The M80-5L13442MC is a Datamate J-Tek series header connector manufactured by Harwin Inc. It features a vertical through-hole mounting style with 34 positions arranged in two rows. The connector utilizes a 2.00mm pitch and includes push-turn locking mechanisms for secure attachment. Contact materials are phosphor bronze with gold plating on mating surfaces and tin on tails. The housing is constructed from black glass-filled polyphenylene sulfide (PPS) rated UL94 V-0. It supports board-to-board or cable applications with a rated current of 2.2A at 120V.

Headers, Male Pins Feature Summary

• Push-turn locking mechanism for rapid and secure hardware mating
• High-reliability construction using glass-filled PPS insulation
• Dual-row configuration supporting high-density interconnects
• Gold-plated contacts ensuring stable signal transmission

Headers, Male Pins Applications

• Industrial control systems requiring robust board-to-board connections
• Test and measurement equipment needing reliable signal integrity
• Automotive electronics modules with vibration resistance requirements
• Medical device instrumentation demanding high reliability

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm pin count, contact plating thickness, and tail length variations. Ensure compatibility with corresponding socket connectors within the Datamate J-Tek family. Confirm RoHS compliance status and material declarations against current regulatory standards before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical header with push-turn locking is required for high-density applications. Consider the 2.00mm pitch constraint and 34-position capacity against available PCB space. Evaluate thermal management needs given the 2.2A rating and operating temperature range of -55°C to 121°C.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate J-Tek family, known for its modular design and hardware mating options. The M80-5L13442MC specifically represents a standard vertical header variant. It complements other components like M80-4C13442FC sockets within the same series ecosystem.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Harwin Datamate J-Tek headers with identical 34-position configurations and push-turn locking features. Verify mechanical dimensions and electrical ratings match exactly before substitution.
