M80-5L15005M7

Headers, Male Pins Overview

The M80-5L15005M7 is a DATAMATE J-TEK DIL male header connector manufactured by Harwin Inc. It features a horizontal mounting style with 50 positions arranged in a dual inline configuration. The connector utilizes a 2.00mm (0.079 inch) pitch and is designed for through-hole termination. Key specifications include a current rating of 2.2A, a voltage rating of 800VAC/DC, and a contact finish thickness of 29.5µin (0.75µm). The housing is black, constructed from glass-filled polyphenylene sulphide, ensuring compliance with UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Horizontal mounting orientation facilitates compact board integration.
• Through-hole soldering provides secure mechanical attachment.
• High voltage rating supports demanding electrical environments.
• Locking mechanism ensures stable connection integrity.

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnections
• Power supply units needing high voltage isolation
• Automotive electronics harnesses
• Test and measurement equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm pin count, pitch, and mounting style match the design requirements. Ensure compatibility with mating female connectors within the DATAMATE J-TEK series. Confirm RoHS3 compliance status if environmental regulations apply. Check datasheet for precise PCB footprint dimensions and recommended soldering profiles to ensure reliable assembly and long-term performance.

Headers, Male Pins Selection Notes

Select this component when a horizontal male header with 50 positions and a 2.00mm pitch is required. Consider the 2.2A current rating and 800VAC/DC voltage capability for circuit suitability. Evaluate the through-hole termination method against available PCB space and manufacturing capabilities. Compare with other Harwin series like Gecko if smaller pitch or different locking mechanisms are needed.

Headers, Male Pins Part Context

This part belongs to the DATAMATE J-TEK family, known for high-density interconnect solutions. It complements female sockets and crimp terminals within the same ecosystem. The horizontal design distinguishes it from vertical variants, offering flexibility in panel or board layout configurations. It serves as a critical interface point in complex electronic assemblies requiring reliable signal and power transmission.

Headers, Male Pins Replacement Considerations

• G125-MH15005L5P

Headers, Male Pins FAQ

What is the contact material for this connector?

The contacts are made from beryllium copper, providing excellent conductivity and spring properties.

Is this connector shielded?

No, this specific model is an unshielded header connector designed for general-purpose interconnection.
