M80-5L15042MC

Headers, Male Pins Overview

The M80-5L15042MC is a Datamate J-Tek series male header connector manufactured by Harwin Inc. It features a 50-position, double-row configuration with a 2.00mm pitch. Designed for through-hole mounting, it utilizes right-angle termination to facilitate horizontal PCB connections. The contacts are constructed from beryllium copper with gold plating on mating surfaces and tin on posts, ensuring reliable signal transmission. Rated for 2.2A current and 120V voltage, the housing is made of black polyphenylene sulfide (PPS) with UL94 V-0 flammability rating. Operating temperature ranges from -55°C to +125°C.

Headers, Male Pins Feature Summary

• High-reliability four-finger beryllium copper contact technology ensures connection integrity without loss.
• Right-angle through-board termination allows for compact horizontal PCB layout integration.
• Shrouded four-wall design provides robust mechanical stability and alignment during mating.

Headers, Male Pins Applications

• Industrial control systems requiring high-density interconnects
• Automotive electronics modules needing reliable signal routing
• Telecommunications equipment utilizing space-constrained board layouts

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm the exact contact finish thickness and post material specifications. Ensure compatibility with mating receptacles from the same Datamate J-Tek family. Confirm that the right-angle orientation matches the intended PCB footprint requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle male header is required for through-hole assembly. The 2.00mm pitch supports dense circuit designs while maintaining adequate spacing. Consider the 2.2A current rating and 120V voltage limit to ensure compliance with system electrical requirements and thermal management strategies.

Headers, Male Pins Part Context

This part belongs to the Datamate J-Tek family, known for its high-reliability interconnect solutions. The M80 series offers various configurations including vertical and right-angle headers. This specific model emphasizes horizontal connectivity through its right-angle design, suitable for applications where vertical clearance is limited but board density is critical.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin Datamate J-Tek male headers with identical 50-position, double-row, right-angle through-hole specifications. Verify matching pitch, contact material, and insulation height when evaluating alternative part numbers within the same manufacturer's portfolio.

Headers, Male Pins FAQ

What is the contact material used in the M80-5L15042MC?

The contacts are made from beryllium copper, featuring gold plating on the mating areas and tin plating on the termination posts.

Does this connector support shrouded mounting?

Yes, the M80-5L15042MC features a shrouded four-wall design to provide mechanical stability and proper alignment during mating.
