M80-5L20222M5-01-334-01-334

Headers, Male Pins Overview

The Harwin M80-5L20222M5-01-334-01-334 is a Datamate L-Tek male header connector designed for power-to-board applications. It features a 4-position configuration with a 2.00mm pitch and 4.00mm row spacing. The component utilizes phosphor bronze contacts with gold plating, housed in black polyamide insulation. Rated for 2.2A per contact and 800V, it supports through-hole solder termination. Operating temperatures range from -55°C to +125°C, ensuring reliability in demanding electronic environments.

Headers, Male Pins Feature Summary

• High-voltage capability up to 800V for specialized power distribution
• Robust gold-plated phosphor bronze contacts for reliable conductivity
• Horizontal orientation design for compact board integration
• Polyamide housing provides thermal stability and mechanical strength

Headers, Male Pins Applications

• Industrial control systems requiring high-voltage isolation
• Power supply modules within electronic assemblies
• Automotive electronics harnesses
• Telecommunications infrastructure equipment

Headers, Male Pins Procurement Notes

Verify the complete part number including suffixes to ensure correct pin count and orientation. Confirm RoHS compliance status prior to ordering as specifications may vary by production batch. Cross-reference datasheet electrical ratings against system requirements to validate current and voltage limits. Ensure soldering profiles match the specified thermal characteristics of the polyamide material.

Headers, Male Pins Selection Notes

Select this connector when horizontal mounting and high-voltage isolation are required. Compare the 2.2A current rating against total load requirements. Consider the 2.00mm pitch for density constraints. Verify mating compatibility with corresponding female sockets in the Datamate L-Tek series. Assess environmental conditions against the -55°C to +125°C operating range.

Headers, Male Pins Part Context

This component belongs to the Harwin Datamate L-Tek series, which focuses on high-reliability power connections. The series is known for its robust mechanical latching and secure mating interface. It complements the broader Datamate ecosystem, offering solutions for both signal and power transmission needs in compact form factors.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available. Direct replacement requires identical electrical ratings and mechanical dimensions. Consult Harwin engineering for potential obsolescence management or alternative series recommendations if this specific configuration is unavailable.

Headers, Male Pins FAQ

What is the maximum voltage rating for this connector?

The M80-5L20222M5-01-334-01-334 has a voltage rating of 800V.

What is the contact material and plating?

The contacts are made of phosphor bronze with gold plating to ensure low resistance and corrosion resistance.

Does this connector support through-hole mounting?

Yes, the component is designed for through-hole solder termination.
