M80-5L20422M5-00-000-02-334

Headers, Male Pins Overview

The Harwin M80-5L20422M5-00-000-02-334 is a Datamate J-Tek power connector designed for board-to-cable applications. It features a male configuration with 40 positions arranged in a dual row. The component utilizes a horizontal mounting style with solder pin termination. Rated for 3 A current and 800 VAC/DC voltage, it employs phosphor bronze contacts with gold plating housed in polyphenylene sulfide (PPS). The connector supports mixed signal and power transmission within a shrouded four-wall design.

Headers, Male Pins Feature Summary

• Supports mixed-signal and power transmission via the Mix-Tek architecture
• Provides secure mating through a shrouded four-wall housing design
• Enables reliable electrical connection using gold-plated phosphor bronze contacts

Headers, Male Pins Applications

• Industrial control systems requiring mixed signal and power distribution
• Medical equipment needing high-voltage isolation capabilities
• Automotive electronics utilizing board-to-cable interconnects

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as documentation indicates non-compliance. Confirm availability due to potential supply constraints. Ensure compatibility with mating female connectors in the Datamate series. Validate voltage ratings against specific application requirements before integration.

Headers, Male Pins Selection Notes

Select this part for applications demanding high voltage tolerance up to 800 VAC/DC. Consider the horizontal orientation and solder pin termination for PCB layout constraints. Evaluate the 40-position capacity against circuit density needs. Ensure environmental conditions align with PPS material specifications.

Headers, Male Pins Part Context

This component belongs to the Harwin Datamate J-Tek family, known for compact mixed-signal connectivity. It integrates power and signal lines in a single interface. The series offers various configurations for diverse electronic assembly requirements. This specific model emphasizes robust electrical performance in space-constrained environments.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available. Verify functional equivalence if considering alternative suppliers. Check dimensional and electrical parameter alignment carefully.
