M80-5L20422M5-02-333-00-000

Headers, Male Pins Overview

The M80-5L20422M5-02-333-00-000 is a Datamate Mix-Tek connector from Harwin, designed for mixed signal and power applications. It features a 2-row configuration with 40 positions, utilizing male pin contacts arranged in a horizontal orientation. The component employs through-hole solder terminals for board mounting and includes jackscrew locking mechanisms to ensure secure connection integrity. Constructed with brass contacts and a black polyphenylene sulfide (PPS) insulator, it supports reliable performance across industrial environments.

Headers, Male Pins Feature Summary

• Integrates mixed-signal capabilities within a single connector housing
• Utilizes jackscrew locking for enhanced mechanical retention
• Features horizontal through-hole termination for surface mounting

Headers, Male Pins Applications

• Industrial control systems requiring mixed signal connections
• Data communication equipment interfaces
• Automotive electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffixes against the official Harwin datasheet to confirm contact plating, insulation material, and locking mechanism variations. Ensure the selected variant matches the required current rating and environmental specifications for the target application. Cross-reference the part number with the manufacturer's latest release notes to confirm availability and compliance status.

Headers, Male Pins Selection Notes

Select this component when a robust, mixed-signal solution is required for horizontal board mounting. The jackscrew feature provides superior retention compared to standard latches, making it suitable for high-vibration environments. Consider the 2mm pitch and 2-row layout for density requirements. Verify that the through-hole termination method aligns with the PCB manufacturing process and thermal constraints of the assembly line.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek series by Harwin, which combines signal and power contacts in one connector system. The series is known for its compact size and high reliability in demanding applications. The M80-5L20422M5-02-333-00-000 specifically represents a 40-position variant with horizontal orientation and jackscrew locking, fitting into the broader ecosystem of Datamate connectors used in industrial and automotive sectors.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other Harwin Datamate Mix-Tek variants with matching position counts and locking mechanisms. Verify compatibility with mating receptacles before replacement. Generic connectors with similar pitch and row count may fit mechanically but will not support mixed-signal integration or jackscrew retention without adapter solutions.
