Product Detailed Parameters
- Description：DATAMATE J-TEK DIL MALE VERTICAL
- Series：Datamate J-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：34
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Tin
- Contact Material：Phosphor Bronze
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：800VAC/DC
Download product information
Overview
The Harwin M80-5S13442MC is a Datamate J-Tek series header connector designed for surface mount applications. It features a 2-row configuration with 34 positions and a 2 mm pitch. The contacts are male pins made of phosphor bronze, finished with gold plating. Rated for 3 A current and operating between -55°C and +125°C, the housing is black polyphenylene sulfide (PPS) with UL94 V-0 flammability rating.
Feature Summary
- Datamate J-Tek series interconnect system
- Surface mount termination style
- Gold-plated male pin contacts
- High-temperature PPS insulation
Applications
- Power to board connections
- Industrial control systems
- Automotive electronics
Procurement Notes
Verify the specific suffix codes against the manufacturer's official documentation to ensure correct contact material, plating thickness, and mounting orientation. Confirm RoHS compliance status through the latest datasheet before procurement.
Selection Notes
Select this component for high-density surface mount designs requiring robust power delivery. Ensure PCB footprint matches the specified SMD dimensions and verify thermal management capabilities for the 3 A rating in the target application environment.
Part Context
This part belongs to the Datamate Mix-Tek family, combining signal and power capabilities. It utilizes the proprietary push-pull locking mechanism for secure mating. The 2 mm pitch allows for compact circuit board layouts while maintaining reliable electrical performance.
Replacement Considerations
M80-5S13442M2-00-000-00-000
FAQ
What is the contact material?
Phosphor bronze.
Is the connector vertical or right-angle?
Straight (vertical) mounting angle.
