M80-5S20605MQ

Overview

The M80-5S20605MQ is a Datamate J-Tek male header connector manufactured by Harwin Inc. It features an 8-position (4+4) dual in-line configuration with a 2.00mm pitch. Designed for surface mount technology, it utilizes right-angle termination for board-to-board or cable applications. The connector operates within a temperature range of -55°C to 125°C and supports up to 800VAC/DC. Contacts are gold-plated brass pins with a thickness of 29.5µin (0.75µm).

Feature Summary

• High reliability construction resistant to 100G shock, 40G bump, and 10G vibration.
• Surface mount right-angle design facilitates compact PCB layout integration.
• Gold-plated contacts ensure stable electrical performance in demanding environments.

Applications

• Board-to-board interconnections requiring high mechanical stability.
• Cable-to-board connections in industrial control systems.
• Harsh environment electronics subject to significant vibration and shock.

Procurement Notes

Verify the specific ordering suffix against the official Harwin catalog to confirm pin count, orientation, and termination style. Ensure compatibility with mating connectors from the same Datamate series. Confirm that the surface mount footprint matches the target PCB design specifications before finalizing procurement orders.

Selection Notes

Select this component when right-angle surface mounting is required for robust signal transmission. The 2.00mm pitch accommodates standard trace widths while providing sufficient spacing. Consider the thermal operating limits and voltage ratings to ensure suitability for the specific circuit requirements and environmental conditions of the application.

Part Context

This part belongs to the Datamate J-Tek family, known for high-reliability rectangular connectors. The series offers various configurations including vertical and horizontal orientations with different contact counts. It is widely used in aerospace, defense, and industrial sectors where connection integrity under stress is critical.

Replacement Considerations

Consult the official Harwin cross-reference guide for verified substitutes. Generic equivalents may not match the specific shock and vibration resistance ratings. Ensure any replacement maintains the 2.00mm pitch and surface mount right-angle form factor.

FAQ

What is the contact material for this connector?

The contacts are made of brass with a gold plating finish.

Is this connector suitable for high-vibration environments?

Yes, it is designed to withstand 10G vibration, 40G bump, and 100G shock.
