Product Detailed Parameters
- Description：CONN HDR 2MM SMT R/A 6POS
- Series：Datamate J-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Surface Mount, Right Angle
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.218" (5.55mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Tin
- Contact Material：Brass
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：800VAC/DC
Download product information
Overview
The M80-5S20642MD is a Datamate J-Tek male header connector manufactured by Harwin Inc. It features a double-row configuration with six positions (3+3) and a 2.00mm pitch. Designed for surface mount technology, it utilizes right-angle termination to facilitate horizontal PCB integration. The contacts are gold-plated brass pins rated for 3A current, housed in black polyphenylene sulfide (PPS). The assembly incorporates 101Lok bayonet locking mechanisms for secure mating.
Feature Summary
- Incorporates 101Lok bayonet receptacles for rapid and simple mating engagement.
- Features right-angle surface mount termination for compact horizontal board layout.
- Constructed with gold-plated brass contacts ensuring reliable signal transmission.
Applications
- Compact electronic device interconnects requiring space-saving profiles
- High-density circuit board assemblies utilizing surface mount technology
- Industrial control systems needing secure bayonet locking connections
Procurement Notes
Verify the specific suffix codes against official Harwin documentation to ensure correct contact plating thickness and housing material variants. Confirm that the right-angle surface mount footprint matches the target PCB design specifications before procurement. Cross-reference the 101Lok locking mechanism requirements with mating connector datasheets to guarantee mechanical compatibility.
Selection Notes
Select this component when a low-profile, right-angle connection is required for high-reliability applications. The 101Lok system offers superior retention compared to standard latches. Ensure the PCB solder mask and copper pad layout accommodate the surface mount tails without shorting adjacent traces due to the angled orientation.
Part Context
This part belongs to the Datamate J-Tek series, known for its robust performance in demanding environments. The M80-5S20642MD specifically addresses needs for small form-factor electronics where vertical headers are impractical. Its design supports automated assembly processes while maintaining high mechanical stability during operation.
Replacement Considerations
M80-5S20642MC
FAQ
What type of locking mechanism does the M80-5S20642MD use?
It uses 101Lok bayonet receptacles designed for fast, simple, and secure mating.
Is this connector suitable for through-hole mounting?
No, it is specifically designed for surface mount technology (SMT) with right-angle termination.
