M80-5T10442MC

Overview

The M80-5T10442MC is a vertical PCB header from the Datamate J-Tek series by Harwin Inc. It features a 2-row, 4-position configuration with a 2.00mm pitch. Designed for through-hole mounting, it utilizes male pin contacts made of phosphor bronze with gold plating on mating surfaces and tin on tails. The housing is constructed from black, glass-filled PPS rated UL94 V-0. Electrical ratings include 2.2A current and 120V voltage. It operates within a temperature range of -55°C to 121°C and employs push-turn locking with a four-wall shield.

Feature Summary

• Push-turn locking mechanism ensures secure connection
• Four-wall shielding provides electromagnetic protection
• High mechanical resistance against shock and vibration
• Compatible with mating flanges and keying slots

Applications

• Industrial control systems requiring high reliability
• Automotive electronics under harsh environmental conditions
• Medical equipment demanding stable signal transmission
• Test and measurement instrumentation

Procurement Notes

Verify the specific ordering suffix to confirm tail length and packaging type. Ensure compatibility with the corresponding female socket series. Check RoHS compliance status if required for your region. Confirm lead times as they may vary based on production schedules. Validate that the selected variant matches the required current and voltage ratings for the application.

Selection Notes

Select this component when a vertical, low-profile header with robust mechanical retention is needed. The 2.00mm pitch allows for dense circuit board layouts. Consider the push-turn lock for applications subject to vibration. Ensure the mating connector supports the same keying and flange requirements. Verify thermal performance meets the operating environment limits.

Part Context

This part belongs to the Datamate J-Tek family, known for high-reliability interconnects. The series offers various configurations including surface mount and cable versions. It is designed for demanding environments where standard connectors might fail. The M80-5T10442MC specifically addresses vertical board-to-board connections.

Replacement Considerations

No direct public substitute part numbers are confirmed in the provided documentation. Cross-reference with other Harwin Datamate variants for similar pitch and locking mechanisms. Ensure mechanical dimensions and electrical ratings match before substitution.
