Product Detailed Parameters
- Description：CONN HEADER VERT 10POS 2MM
- Series：Datamate Mix-Tek
- Mfr：Harwin Inc.
- Package：Bag
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：10 (6 + 4 Power)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：-
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The M80-5T10605M3-04-332-00-000 is a board connector from the Harwin Datamate J-Tek series. It features a vertical header configuration with 10 positions arranged in two rows (6 signal and 4 power). The connector utilizes a 2.00mm pitch and supports through-hole termination. Key specifications include a rated current of 2.2A, a voltage rating of 120V, and an operating temperature range of -55°C to 121°C. The housing is constructed from black glass-filled polyphenylene sulfide (PPS) with UL94 V-0 flammability ratings.
Feature Summary
- Push-turn locking mechanism for secure mating
- Hybrid contact design combining signal and power pins
- Four-wall shielding for enhanced protection
Applications
- Industrial control systems requiring high reliability
- Medical equipment with strict safety standards
- Automotive electronics applications
Procurement Notes
Verify the specific ordering suffixes against the official Harwin datasheet to ensure correct pin count, termination style, and latch type. Confirm that the hybrid configuration matches the system requirements for both signal and power distribution. Check for RoHS compliance status and material certifications required by the target industry regulations before finalizing procurement orders.
Selection Notes
Select this component when a vertical, locked interconnect solution is needed for mixed signal and power lines. Ensure the PCB layout accommodates the 2.00mm spacing and the mechanical footprint of the push-turn latches. Consider the thermal environment, as the PPS material supports temperatures up to 121°C. Verify mating compatibility with the corresponding female receptacle from the same Datamate J-Tek family.
Part Context
This part belongs to the Harwin Datamate J-Tek series, known for its compact size and robust performance. The M80 series specifically offers high-density interconnects suitable for space-constrained designs. The model number indicates a 10-position header with a specific keying slot and termination style, ensuring precise alignment and reliable electrical connections in demanding environments.
Replacement Considerations
Direct substitutes within the Datamate J-Tek family must maintain the 10-position count, 2.00mm pitch, and vertical orientation. Verify that any alternative part number shares the same push-turn locking mechanism and hybrid contact arrangement. Cross-reference the mechanical dimensions and mounting hole patterns to ensure PCB compatibility without redesign.
