M80-5T10642M1-03-331-00-000

Overview

The M80-5T10642M1-03-331-00-000 is a Datamate J-Tek header connector manufactured by Harwin Inc. It features a vertical through-hole mounting style with six positions arranged in two rows. The connector utilizes a 2.00mm pitch for mating contacts and includes a push-turn locking mechanism for secure attachment. The housing is constructed from black glass-filled polyphenylene sulfide (PPS) rated UL94 V-0. Contacts are made of phosphor bronze with gold plating on the mating surface and tin plating on the tail.

Feature Summary

• Push-turn locking mechanism ensures secure board-to-board or cable connections without requiring additional screws.
• Keyed design prevents incorrect mating orientation between header and socket components.
• High-temperature resistant PPS insulation supports operation across a wide thermal range.
• Gold-plated contact surfaces provide reliable signal transmission and corrosion resistance.

Applications

• Industrial control systems requiring robust interconnects
• Medical equipment demanding high reliability and sterilization compatibility
• Automotive electronics subject to vibration and thermal stress
• Test and measurement instrumentation interfaces

Procurement Notes

Verify the specific suffix codes against the official Harwin configuration tool to ensure exact mechanical and electrical specifications. Confirm RoHS compliance status for the specific production batch if required by project regulations. Cross-reference the DigiKey part number 952-1277-5-ND for accurate distributor identification and lead time assessment before finalizing procurement orders.

Selection Notes

Select this component when a vertical, keyed header with a positive locking mechanism is required for 2.00mm pitch applications. Ensure the mating socket matches the Datamate J-Tek series specifications. Verify that the PCB layout accommodates the through-hole termination style and the physical dimensions of the locking collar during assembly.

Part Context

This part belongs to the Datamate J-Tek family, known for its compact size and high-density capabilities. The M80-5T10642M1 variant specifically denotes a male header with a standard tail length and specific locking features. It is designed for environments where vibration resistance and secure connection integrity are critical operational requirements.

Replacement Considerations

Direct substitutes within the same series include variations in tail length or locking type, such as M80-5T10642MC. Ensure any replacement maintains the 2.00mm pitch and keying configuration to guarantee mechanical fit and electrical continuity with existing mating connectors.

FAQ

What is the locking mechanism type for this connector?

The M80-5T10642M1-03-331-00-000 uses a push-turn locking mechanism, which provides a secure connection without the need for jackscrews.

What material is used for the contact plating?

The mating contacts are plated with gold to ensure low contact resistance and reliable performance over multiple mating cycles.
