Product Detailed Parameters
- Description：CONN HEADER VERT 10POS 2MM
- Series：Datamate Mix-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：10 (6 + 4 Power)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：-
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The M80-5T10642M2-00-000-04-331 is a Datamate J-Tek male header connector manufactured by Harwin Inc. It features a vertical through-hole mounting style with six positions arranged in a single row. The connector utilizes a 2.00mm pitch and incorporates beryllium copper contacts with gold plating for reliable signal transmission. Designed for power-to-board applications, it offers high-reliability performance suitable for embedded communication systems.
Feature Summary
- Utilizes four-finger beryllium copper contact technology to ensure connection integrity without loss
- Features a vertical pin configuration designed for board-to-board or cable connections
- Incorporates push-turn locking mechanism for secure attachment
Applications
- Embedded communication systems
- Power-to-board interconnections
- High-reliability industrial equipment
Procurement Notes
Verify the specific ordering suffixes against the official Harwin datasheet to confirm exact pin count, contact material, and termination type. Ensure compatibility with mating female connectors within the Datamate J-Tek series. Confirm that the vertical orientation and through-hole termination meet the target PCB layout requirements before finalizing procurement orders.
Selection Notes
Select this component when a single-row, vertical male header is required for robust signal or power transfer. The Datamate J-Tek series provides a compact footprint with high cycle durability. Consider the specific stacking height requirements and locking mechanism needs when evaluating alternative connectors in the same family.
Part Context
This part belongs to the Datamate J-Tek family, known for high-reliability interconnect solutions. The M80-5T10642M2 variant specifically denotes a male header with defined physical dimensions and contact specifications. It complements the broader range of Harwin connectors designed for demanding electronic environments.
Replacement Considerations
Consult the Harwin cross-reference tool for parametrically similar parts. Verify that any substitute maintains the 2.00mm pitch, single-row configuration, and compatible locking mechanism to ensure mechanical and electrical interchangeability.
