Product Detailed Parameters
- Description：DATAMATE 2-ROW MIX-TEK MALE VERT
- Series：Datamate Mix-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：10 (8 + 2 Power)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy, Phosphor Bronze
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A, 20A
- Voltage Rating：800VAC/DC
Download product information
Overview
The Harwin M80-5T10805M2-02-331-00-000 is a Power to the Board connector from the DataMate Mix-Tek series. It features a male vertical PCB header configuration with five positions, specifically arranged as three signal contacts and two power contacts. The connector utilizes a 2.00mm pitch and employs Polyphenylene Sulfide (PPS) insulation material reinforced with glass fill for enhanced thermal stability. Designed for direct surface mounting, this component supports robust electrical connections in compact board-to-board applications requiring mixed signal and power transmission capabilities.
Feature Summary
- Vertical through-hole mounting design for direct PCB integration
- Mixed-signal architecture combining signal and power contacts in a single row
- Glass-filled PPS insulation providing high thermal resistance
Applications
- Industrial control systems requiring mixed signal and power interfaces
- Compact electronic modules needing vertical board-to-board connectivity
- Power distribution units integrating signal monitoring
Procurement Notes
Verify the specific contact arrangement and insulation material against project requirements before procurement. Confirm that the vertical orientation and 2.00mm pitch align with the target PCB layout. Ensure compatibility with mating connectors within the DataMate Mix-Tek family. Check for any RoHS compliance status if required by regulatory standards. Validate mechanical locking features if vibration resistance is critical.
Selection Notes
Select this component when a vertical, mixed-signal solution is necessary for space-constrained designs. The combination of signal and power contacts in a single header simplifies assembly compared to separate connectors. Consider the thermal properties of the glass-filled PPS material for environments with elevated temperatures. Ensure the mating connector matches the female counterpart specifications for reliable engagement.
Part Context
This part belongs to the Harwin DataMate Mix-Tek family, designed for versatile interconnect solutions. The series allows for flexible contact arrangements, accommodating both signal and power needs in a unified housing. The vertical form factor distinguishes it from horizontal variants, offering different spatial advantages for PCB stacking or edge-mounting configurations.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing mating hardware before considering alternative sources.
