Product Detailed Parameters
- Description：CONN HEADER VERT 14POS 2MM
- Series：Datamate Mix-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：14 (12 + 2 Power)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：-
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The M80-5T11205M1-02-331-00-000 is a 6-position (4 signal + 2 power) rectangular connector header from the Datamate Mix-Tek series by Harwin Inc. It features a 2.00mm pitch, vertical through-hole solder termination, and gold-plated contacts. The unit includes an integrated backshell with four-wall shielding for EMI protection and utilizes threaded locking mechanisms.
Feature Summary
- Integrated four-wall shielded backshell provides electromagnetic interference protection
- Threaded locking mechanism ensures secure mechanical connection integrity
- Gold-plated beryllium copper contacts ensure reliable electrical performance
- Vertical through-hole design facilitates direct printed circuit board mounting
Applications
- Industrial control systems requiring robust vibration resistance
- Aerospace and defense electronic assemblies
- Automotive electronics in high-interference environments
- Medical equipment demanding high reliability
Procurement Notes
Verify the specific ordering suffix to confirm the presence of the integrated backshell and shielding configuration. Ensure compatibility with mating socket connectors within the same Datamate Mix-Tek series. Confirm that the required pin count matches the 4+2 power arrangement specified for this part number before procurement.
Selection Notes
Select this component when a shielded, vertically mounted header with threaded locking is required. It is suitable for applications needing high durability against shock and vibration. Consider the 2.00mm pitch constraint and the need for through-hole soldering during PCB layout design.
Part Context
This part belongs to the Datamate Mix-Tek family, known for high-reliability interconnects. It complements mating sockets and cable assemblies within the M80 series ecosystem. The design supports harsh environment operation with certified material properties and rigorous testing standards.
Replacement Considerations
Direct substitutes are limited due to unique suffix configurations. Check Harwin's official cross-reference guides for equivalent Mix-Tek headers with identical shielding and locking features. Generic 2.00mm headers may not provide the same mechanical or shielding performance.
FAQ
Does this connector include an integrated backshell?
Yes, the M80-5T11205M1-02-331-00-000 includes an integrated four-wall shielded backshell.
What is the contact arrangement?
It features a 6-position arrangement consisting of 4 signal pins and 2 power pins.
