M80-5T11205M2-04-331-00-000

Overview

The M80-5T11205M2-04-331-00-000 is a Datamate Mix-Tek header connector manufactured by Harwin Inc. It features a vertical, through-hole termination style with a 2mm mating pitch and two rows of contacts. The assembly includes six positions, configured as four signal pins and two power pins rated for 12AWG wire. The housing is constructed from black PPS material reinforced with glass fiber, meeting UL94 V-0 flammability standards. Contact surfaces are gold-plated to ensure reliable conductivity.

Feature Summary

• Datamate Mix-Tek architecture combines high-current power capabilities with dense signal routing in a single compact form factor.
• Four-finger beryllium copper contact structure provides secure retention and maintains connection integrity under vibration and shock.
• Integrated keying slots and mounting flanges facilitate precise alignment and mechanical stability during board-to-board or cable connections.

Applications

• High-power motor control cabinets
• Industrial automation systems requiring robust interconnects
• Equipment operating in environments with high vibration and acceleration

Procurement Notes

Verify the specific suffix codes against the official Harwin datasheet to confirm pin count, contact type, and housing variations. Ensure that the required mating accessories, such as backsells or locking mechanisms, are included in the procurement list, as they are often sold separately. Confirm that the component matches the intended PCB footprint and stacking height requirements before finalizing orders.

Selection Notes

Select this component when applications demand simultaneous high-current delivery and multi-signal transmission within a restricted space. The Mix-Tek series is suitable for designs requiring flexible configuration options between power and signal lines. Evaluate the thermal environment to ensure the -55°C to 125°C operating range meets system specifications without derating concerns.

Part Context

This part belongs to the Datamate Mix-Tek family, designed for demanding industrial and automotive sectors. It complements other Harwin connectors like the J-Tek and L-Tek series by offering a hybrid solution. The M80-5T1 base number indicates the core header design, while the extended suffix defines the specific terminal and housing attributes for this unique configuration.

Replacement Considerations

No public confirmed substitute part numbers are available. Direct replacement requires matching the exact Datamate Mix-Tek specifications, including the 2mm pitch and mixed signal/power layout. Alternative solutions may require redesigning the PCB footprint and verifying mechanical compatibility with existing mating interfaces.
