Product Detailed Parameters
- Description：CONN HEADER VERT 16POS 2MM
- Series：Datamate Mix-Tek
- Mfr：Harwin Inc.
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：16 (12 + 4 Power)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：-
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The M80-5T11242M3-04-331-00-000 is a vertical board-to-board connector from the Harwin Datamate Mix-Tek series. It features a 16-position configuration with a 2mm pitch. The component utilizes gold-plated contacts and a black insulator made of glass-filled polyphenylene sulfide. Designed for surface mount or through-hole applications, it supports reliable electrical interconnection in demanding environments.
Feature Summary
- Vertical header design for direct board mounting
- Gold-plated contact finish for corrosion resistance
- Glass-filled PPS insulator for thermal stability
Applications
- High-power motor control cabinets
- Industrial automation systems
- Embedded electronic modules
Procurement Notes
Verify the specific suffix codes against official Harwin documentation to ensure correct pin count and termination style. Confirm RoHS compliance status and lead times directly with authorized distributors. Cross-reference the full part number to avoid mismatches in housing color or contact plating specifications.
Selection Notes
Select this connector when a 16-position vertical interface is required. Ensure PCB layout accommodates the 2mm pitch and mounting footprint. Verify mating compatibility with corresponding female sockets from the same Datamate Mix-Tek family. Check mechanical constraints for height and stacking requirements.
Part Context
This component belongs to the Datamate Mix-Tek product line by Harwin Inc. The series is engineered for mixed signal and power applications. It offers high density and robust mechanical locking. The part integrates seamlessly into compact electronic assemblies requiring reliable connectivity.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided data. Consult Harwin engineering for potential equivalents if this specific variant is unavailable.
