M80-5T13442M3

Overview

The Harwin M80-5T13442M3 is a Datamate J-Tek male pin header designed for power-to-board applications. It features a 2-row configuration with 34 positions and a 2 mm pitch. The connector utilizes brass contacts with gold plating and a black polyphenylene sulfide (PPS) insulator. Rated for 3 A current, it supports solder termination in a surface mount or through-hole straight installation style. Operating temperatures range from -55 C to +125 C, with an insulation resistance of 100 MOhms.

Feature Summary

• High-reliability four-finger beryllium copper contact technology ensures connection integrity without loss.
• Datamate J-Tek series design provides robust mechanical locking capabilities.
• Gold-plated brass contacts offer superior conductivity and corrosion resistance.

Applications

• Industrial control systems requiring high-reliability interconnects
• Motor control applications demanding stable system response
• Power distribution boards needing secure male pin connections

Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm terminal type and latch configuration. Ensure compatibility with mating female connectors within the Datamate J-Tek family. Confirm that the selected variant matches the required PCB mounting style and current rating specifications for the target application environment.

Selection Notes

Select this component when a 34-position male header with 2 mm pitch is required for power-to-board interfaces. Consider the 3 A current rating and wide temperature range for harsh environments. Verify that the straight installation style and solder termination method align with the PCB layout and assembly process requirements.

Part Context

This part belongs to the Harwin Datamate J-Tek series, known for high-reliability board-to-board and wire-to-board connections. The M80 prefix indicates the standard Datamate form factor. The model number specifies the row count, position, and contact type, distinguishing it from other variants in the extensive Harwin connector portfolio.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other Harwin Datamate J-Tek headers only if electrical and mechanical parameters match exactly.
