Product Detailed Parameters
- Description：DATAMATE J-TEK DIL MALE VERTICAL
- Series：Datamate J-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：0.173" (4.40mm)
- Overall Contact Length：-
- Insulation Height：0.220" (5.60mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Gold
- Contact Material：Phosphor Bronze
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware, Shielded
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：800VAC/DC
Download product information
Overview
The Harwin M80-5T20605MF is a Datamate J-Tek board-to-board connector featuring 6 positions arranged in a dual in-line configuration. It utilizes a 2.00mm pitch and employs male pin contacts with solder termination for vertical through-board mounting. The unit includes M2x0.4 jackscrew locking mechanisms and incorporates a bore feature within the housing.
Feature Summary
- Vertical through-board mounting style with solder termination
- Dual in-line configuration with male pin contacts
- Integrated M2x0.4 jackscrew locking mechanism
- Housing design includes a specific bore feature
Applications
- Board-to-board interconnects requiring secure mechanical locking
- High-density electronic assemblies utilizing 2.00mm pitch spacing
- Applications demanding vertical orientation for space-constrained designs
Procurement Notes
Verify the exact suffix against official Harwin documentation to confirm the presence of the bore feature and jackscrew specifications. Ensure compatibility with mating female connectors within the Datamate J-Tek series. Confirm that the vertical through-board form factor aligns with the target PCB layout requirements before finalizing procurement.
Selection Notes
Select this component when a locked, vertical interconnect solution is required for high-density applications. The male contact type necessitates pairing with compatible female counterparts. Verify that the M2x0.4 jackscrew interface meets the mechanical retention needs of the assembly environment.
Part Context
This part belongs to the Datamate J-Tek series by Harwin Inc., designed for power-to-board and signal interconnects. The series is characterized by its robust locking mechanisms and compact 2.00mm pitch, suitable for demanding industrial and commercial electronics environments.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided source material. Consult official Harwin documentation for potential cross-reference options or updated series equivalents.
