M80-6660622

Overview

The Harwin M80-6660622 is a Datamate L-Tek series male header connector featuring a 3+3 position configuration with a 2.00mm pitch. It utilizes surface-mount technology in a right-angle orientation, designed for horizontal mating. The contacts are constructed from brass with gold plating on the mating interface and tin plating on the posts. Rated for 3A current and 360V voltage, it operates within a temperature range of -55°C to +125°C. The housing is black polyamide.

Feature Summary

• Fully shrouded design ensures polarized mating and prevents pin misalignment during assembly.
• Right-angle surface mount termination facilitates compact board layout and horizontal cable routing.
• Latched locking mechanism provides secure connection retention between header and socket components.

Applications

• Industrial control systems requiring reliable signal transmission
• Consumer electronics with space-constrained PCB layouts
• Automotive infotainment and sensor interfaces

Procurement Notes

Verify the specific ordering suffix to confirm contact finish specifications, as variations exist between gold/tin combinations. Ensure compatibility with the corresponding female socket from the same Datamate L-Tek family. Confirm that the right-angle SMT footprint matches the target PCB design constraints before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, right-angle interconnect solution is required for horizontal mating applications. The 2.00mm pitch allows for dense circuit arrangements while maintaining adequate spacing. Consider the current rating and voltage limits against the system requirements to ensure safe operation under load conditions.

Part Context

This part belongs to the Datamate L-Tek family, characterized by its robust mechanical latching and high-density capabilities. It serves as a male header counterpart to various female sockets within the same series, enabling versatile connectivity options for both board-to-board and wire-to-board applications in Harwin's connector portfolio.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific configuration.
